Geetha Venkatesan, Rajagopalan Vijayaraghavan*, Sarada Nallani Chakravarthula, Govindasamy Sathiyan
Department of Chemistry, School of Advanced Sciences, VIT University, Vellore-632014, Tamil Nadu, India
Frontier Research Today, 2019, 2, 2002
Published Online: 25 April 2019 (Article)
ABSTRACT: The use of Boswellia ovalifoliolata bark extract for the synthesis of zinc oxide nanoparticles (ZnO NPs) with benefits of eco-friendliness, low cost and compatibility for pharmaceutical and biological applications. In this paper, we report the biosynthesis of zinc oxide nanoparticles using plant extract and its application for the detection of picric acid (PA). The synthesized ZnO nanoparticles were characterized using UV-Vis spectroscopy, scanning electron microscopy (SEM), X-ray diffraction pattern (XRD), fourier transform infrared spectroscopy (FT-IR) and fluorescene spectroscopy. ZnO NPs in aqueous solution shows maximum absorption bands at 278 nm and fluorescence emission at 317 nm. The fluorescence emission of zinc oxide nanoparticle shows high selectivity towards picric acid (PA) and can be used as a fluorescent probe for the detection of PA via fluorescence quenching mechanism. The fluorescence quenching mechanism of picric acid may be due to the electron transfer process between ZnO NPs and picric acid which is confirmed by cyclic voltammetry (CV). The quenching efficiency of nanoparticle was calculated using Stern-Volmer equation. The limit of detection was found to be 1.83 µM for picric acid. The fluorescence property of the ZnO NPs can be utilized for cell imaging application as biosensors and also in the field of drug delivery.
Boswellia ovalifoliolata; Zinc oxide nanoparticle; Picric acid; Nitroaromatic compound;
The development of sensitive and selective methods for the detection of nitroaromatics (NACs) explosives has been a field of enormous interest to researchers1. Picric acid is highly water soluble, strong organic acid and it is widely used as a powerful explosive like other NACs and is also a non-biodegradable environmental pollutant which causes skin and eye irritation, cancer, gastritis, aplastic anemia and liver damage2,3. As compare with other NACs detection of picric acid (PA) is more important because of usage in the manufacture of rocket fuels, dye industries, fireworks, pharmaceuticals, deadly explosives, components in matches and chemical laboratories4,9. Picric acid is more dangerous in the dehydrated state, which can easily undergo spontaneous detonation to cause an explosion and it is more explosive than trinitrotoluene (TNT). In spite of all the awareness, PA has been released to the environment during explosives manufacturing, loading and in military installation for packing activities3,4. Different methods have been employed for the detection of NACs such as ionic liquids, X-ray diffraction, organic gels, neutron activation, Raman spectroscopy, electrochemical, metal-organic frameworks, nanoparticle, polymers, quantum dots, ion mobility in solution and vapor phase which are high cost effective and are not easily accessible5,6,12. Hence, fluorescence quenching based sensing is widely used and proven to be highly sensitive6, selective26, fast, low cost1, and simple instrumentation6.
Plant mediated synthesis of metal nanoparticle is gaining an advantage over physical and chemical method because it is one of the biocompatible, nontoxic, eco-friendly, low cost and simplicity in methods17, wherein the chemical method uses the organic solvent, toxic reducing and chelating agent leads to threatening of the environment in various fields18. The high-water solubility of nanoparticle has a various application due to its biocompatible and non-toxic stabilizers. Among all the metal oxide nanoparticles, many research groups are focusing on ZnO NPs for the various applications like sensors, coating, cosmetics, environmental protection, biology19, electronics, communication and medicinal industry along with its biological application like biological sensing, labelling, gene delivery, drug delivery and nanomedicine20. A few reports are available on the luminescent sensors of zinc oxide nanoparticles (ZnO NPs) for the detection of metal ions and detection of organic molecules34. Muk et al. reported on luminescent ZnO NPs as Cu2+ sensors by quenching mechanism. Sharma et al. obtained imine linked ZnO NPs for Co2+ sensor8. The imine linked receptor coated on the ZnO NPs is responsible for the Co2+ sensing9. Zhao et al. have studied the APTES capped luminescent ZnO NPs for the selective and sensitive detection of dopamine by quenching of their luminescent10. Singh et al., synthesized water stable APTES capped ZnO NPs for the selective and sensitive detection of PA11.
Boswellia ovalifoliolata (N.P.Balakr. & A.N.Henry) belongs to the family burseraceae. It is a habitat of seshachalam hill range of the eastern ghats of India. The plant is widely used by the tribal people like nakkala, sugali, chenchu to treat a number of ailments. Leaf, gum, and stem bark extract of the plant found to be anti-inflammatory, analgesic, cardiotoxicity21, cytotoxic22 and hepatoprotective activity23.
Herein, we report the green synthesis of ZnO nanoparticle using Boswellia ovalifoliolata extract and synthesized NPs were characterized using UV-visible (UV-vis) spectroscopy, X-ray diffraction (XRD), Fourier transformed infrared spectroscopy (FT-IR). Morphology of the synthesized NPs was examined by scanning electron microscopy (SEM) and the fluorescence property of NPs was measured using fluorescence spectroscopy (FL). The synthesized NPs exhibits strong fluorescent emission effect which can act as a chemo sensor for detection of PA which is a powerful explosive among other NACs. To the best of our knowledge, there is no literature available for the detection of picric acid by ZnO nanoparticle using plant extract for the synthesis of nanoparticle by greener approach. Thus, the synthesized ZnO nanoparticle is highly selective, sensitive, low cost and efficient in sensing picric acid.
Boswellia ovalifoliolata (BO) was collected from seshachalam hills of Andhra Pradesh during the month of February 2015 and authenticated by Plant Anatomy Research Centre, Chennai (PARC/2015/3202). Zinc acetate was purchased from Sigma Aldrich whereas sodium hydroxide (NaOH), picric acid (PA), 4-nitrophenol (NP), 2,4-dinitrophenol (DNP), 3-nitrobenzoic acid (NBA), 2,4-dinitrotoluene (DNT) were obtained from SD Fine-Chem Limited. 1,3-dinitro benzene (DNB), 4-nitrobenzaldehyde (BAO), nitrobenzene (NB), 4-nitrotoluene (NT) were purchased from Avra Laboratories private limited.
2.2.1 Preparation of B. ovalifoliolata bark extract
About 5 g of B.ovalifoliolata bark were used for synthesis of ZnO nanoparticles. The bark powder was dissolved in 100 ml of distilled water and transferred into an Erlenmeyer flask boiled at 80 ºC for 30 min. The bark extract was filtered through Whatmann No.1 filter paper and the material was stored at 4 °C for the further use. The obtained bark extract (pH 6.0) will control size and shape of the nanoparticle. It will also act as a stabilizer for NPs synthesis19,20,24,25.
2.2.2 Green synthesis of ZnO NPs using B. ovalifoliolata bark extract
About 10 ml of bark extract was mixed with 90 ml of 5 mM zinc acetate in aqueous solution with continuous stirring using a magnetic stirrer at 37 °C for 1 h. The precursor and bark extract composition 1:9 volume ratio was prepared for the synthesis. After 1 h, 1 M sodium hydroxide solution was added in drops to maintain the pH 8 and kept for continuous stirring for 1 h. The yellowish white colour precipitate was centrifuged at 4,000 rpm for 20 min and the precipitate was washed with ethanol for three times to remove impurities present in the final product and the powder will be dried in an oven at 100 ºC for 5 h19,20,24.
2.2.3 Characterization of NPs
The formation of NPs is confirmed by UV-visible absorption spectra measured by a JASCO V-670 spectrophotometer at room temperature wavelength range between 200-800 nm. The FTIR of the bark extract and NPs were recorded by a SHIMADZU Infrared spectrophotometer (400-4000 cm-1) resolution IV. Fluorescence spectra were measured using Hitachi F-7000FL spectrometer with 150 W Xe lamp as excitation source. The surface morphology and particle size of the synthesized nanoparticles were examined using SEM using Carl Zeiss EVO 18, Germany and X-ray diffraction (XRD) method using Bruker D8 advanced through Ni-filtered Cu Kα (λ = 0.15406 nm) with the range of 2θ = 10-90°. High-Resolution Transmission electron microscope (HR-TEM) were recorded by using Transmission Electron Microscopy (TEM), (Model JSM 6390 LV, JOEL, USA). A drop of ZnO NPs was coated over the surface of the copper grid and the grid was dried. For SEM analysis, the samples were coated in cover slips.
2.2.4 Cyclic voltammetry analysis
The electrochemical study was carried out using cyclic voltammetry at different scan rate. A three-electrode system consists of glassy carbon electrode as working electrode (WE), platinum counter electrode and saturated silver and silver chloride as reference electrode (RE). 0.1 M of Tetrabutylammonium tetrafluoroborate (TBAF) was used as a supporting electrolyte for the analysis.
2.2.5 Fluorescence microscopy
Fluorescence microscopy was used to evaluate the bioimaging application of the ZnO NPs and to assess the labelling capability of the nanoparticle. The nanoparticle was prepared and suspended in PBS pH 7.4 (0.1M) and the nanoparticle fluorescence images were recorded using Fluorescence microscope (FM 3000, Wesmox, India).
3 RESULTS AND DISCUSSION
ZnO nanoparticle was synthesized using Boswellia ovalifoliolata extract due to the higher content of polyphenol may be responsible for the ZnO NPs formation. The aromatic hydroxyl presents in the Boswellia ovalifoliolata interact with zinc ions to form the complex in acidic medium and the precipitate formation started at pH 8.018,23. The presence of phytochemicals in the extract like polyphenols, terpenoids tannins, anthocyanins and steroids act as a capping agent in the formation of ZnO NPs.
The prepared ZnO NP were characterized by X-ray diffraction pattern to confirm crystallinity and phase formation of the nanoparticle. XRD pattern of the sample were shown in Figure 1 and the detected peaks corresponds to the hexagonal phase in the lattice planes of (100), (002), (101), (102), (110), (103), (200), (112) and (201) shows 2θ values at 31.7°, 34.48°, 36.18°, 47.52°, 56.53, 63.01°, 66.33°, 68.09° and 68.94°. The crystallinity of sample with narrow peak confirmed the ZnO NPs formation. The morphology and size were observed using scanning electron microscope20. The average crystallite size of the synthesized nanoparticle was found to be 17.7 nm. It is noteworthy, compare to chemical method Figure S1 (43.51 nm), nanoparticle synthesized using plant extract showed reduced and control over size. The plant extract use to control the size of the nanoparticle and act as a stabilizing agent21.
Figure 1. XRD pattern of ZnO nanoparticle synthesized from Boswellia ovalifoliolata extract.
3.1 FTIR analysis of ZnO NPs
The FT-IR spectra of ZnO NPs-picric acid, ZnO NPs and extracts are shown in Figure S2. The chemical structure of the synthesized compound is obtained in the region of 4000-400 cm-1. ZnO NPs- picric acid showed prominent Ar-NO2 bands at 1568 and 1363 cm-1. The bands at 3523-3326 cm-1 correspond to O-H mode of vibration18. We observed an alkyl C-H peak at 2858 cm-1. The ZnO peak appears in the range of 530 cm-1 confirming the ZnO formation20,24. The bands of aromatic compounds around 757, 902 and 1063 cm-1 corresponds to stretching of aromatic C-H and stretching of alcoholic C-O, Figure S2 shows a new peak at 1715 cm-1 of C=O stretching in ZnO-picric acid25,35. The peaks intensity of ZnO-Picric acid was relatively reduced than ZnO NPs which may be due to the quenching effect of picric acid by removal of the organic compound from ZnO NPs25. The nanoparticle is stabilized by the organic compound in the plant extract by the surface bound by their organic compounds. The phenolic compounds in the plant extract had a tendency to coordinate with zinc ions, thus stabilizing and preventing ZnO nanoparticle from being agglomerated. The results confirm that bioactive compounds were absorbed on the surface of ZnO nanoparticles. In this study, Boswellia ovalifoliolata extract was used for the synthesis, capping and chelating agents of nanoparticles.
3.2 Transmission Electron Microscopy (TEM) analysis
ZnO NPs was dispersed in ethanol in a carbon coated copper grid and the TEM image of ZnO NPs is shown in Figure 2. The HR-TEM image indicates that the ZnO NPs are slightly agglomerated and spherical in shape. The average particle size of the synthesized nanoparticle was found to be 11.6 ± 4 nm.
Figure 2. TEM images of ZnO nanoparticle in 50 nm.
3.3 Photo physical properties of ZnO NPs
The photo physical properties of ZnO NPs using UV-visible spectra in aqueous solution were measured. Similarly, the fluorescence spectra were recorded in the range between 200-450 nm. ZnO NPs in aqueous solution shows maximum absorption bands at 278 nm and fluorescence emission at 317 nm. The low fluorescence emission of the ZnO nanoparticle may be due to the intrinsic defects produced by the ZnO nanoparticle such as interstitial zinc and oxygen vacancy and these defects will affect the fluorescence behaviour of the nanoparticle14,15. The high-energy absorption band in the region 278 nm can indicate the π-π* electron transition of phytochemicals in the plant extract such as phenols, tannins, steroids and terpenoids12,13. The photo physical property of the ZnO NP using UV-vis and fluorescence spectroscopy techniques aqueous solution, concentration were maintained at 10 mg/L. The green color fluorescence image of the nanoparticle adsorbed on a TLC plate are shown in Figure 3a. The green emission of the ZnO nanoparticle may be due to the oxygen vacancies located on the surfaces. The blue emission may be due to the zinc vacancies14,15.
Figure 3. Fluorescence image (under 365 nm UV light) of a) ZnO nanoparticle adsorbed on a TLC plate and b) ZnO nanoparticle with a spot of PA solution.
3.4 Scanning electron microscopy (SEM)
The surface morphological nature of the ZnO NPs is investigated using SEM techniques. The SEM images of ZnO NPs showed agglomerated nanoparticle Figure 4a7,16,27. Addition of PA leads to a microstructural changes. The addition of PA molecules leading to the formation of irregular square like structure with length of about 2 µm Figure 4b of the SEM image allows the migration of excitons in a large number of channels which ultimately results in sensitivity towards picric acid. The elemental composition of ZnO nanoparticle obtained from EDAX analysis (Figure 4c) was Zinc (48.52%), Oxygen (28.83 %) and Carbon (22.65%). The presence of carbon indicates the connection of plant phytochemicals in size reduction and in capping of the synthesized ZnO NPs18.
Figure 4. Scanning electron microscopy (SEM) images of a) ZnO nanoparticle, b) after PA addition and c) EDAX spectrum of ZnO nanoparticle.
3.5 Detection of picric acid (PA)
The strong emission of nanoparticle in aqueous solution encouraged us to explore their possible application as chemosensor for the detection of nitroaromatic compounds such as picric acid (PA), dinitrotoluene (DNT), nitrobenzene (NB), nitrophenol (NP), 4-nitrobenzaldehyde (BAO), dinitrobenzene (BNB), dinitrophenol (DNP), 4-nitrobenzoic acid (NBA) and nitrotoluene (NT). The detection of nitroaromatic compounds has attracted many researchers to fight against terrorism and environmental impact26. A number of techniques used for the detection of nitroaromatic compounds, but fluorescence-based detection offers many advantages like high sensitivity, short response time and specificity1. The fluorescence based detection of NACs in presence of ZnO NPs as the chemo sensor was performed by using UV-vis and fluorescence titrations and the analytes were taken in very low concentration. To evaluate the selectivity of ZnO NPs towards PA, the fluorescence quenching efficiency of different nitro compounds were investigated. Initially, the UV-vis titration of ZnO NP with the NACs and the spectra obtained are shown in Figure S3. The UV-vis absorption spectra of ZnO NPs increase for specific analyte PA. The UV-vis titration of NPs was carried out for PA is shown in Figure S4 and the absorbance was gradually increased with the addition of PA.
The fluorescence emission spectra of ZnO NPs with different NACs are displayed in Figure 5. Among all the NACs picric acid showed best quenching efficiency, the decrease in fluorescence intensity indicates the quenching efficiency of PA and the percentage fluorescence quenching intensities are shown in Figure 6. Among the various nitroaromatic compounds tested, the addition of picric acid to the solution of ZnO NPs in aqueous solution results in 70% quenching of fluorescence emission Figure 72,7.
Figure 5. Fluorescence emission spectra of ZnO nanoparticle with different nitroaromatics.
Figure 6. Fluorescence quenching of ZnO nanoparticle with the addition of different nitroaromatics.
Figure 7. Fluorescence emission spectra of ZnO NPs in aqueous solution with PA titration.
We found that the fluorescence property of ZnO nanoparticle can easily be quenched by PA, which allows us to develop a sensor for the detection of PA. PA showed more quenching efficiency than other explosives. The fluorescence of the ZnO NPs was partially quenched by other NACs, the quenching efficiency was much lesser than that of PA. In general, nitro aromatic compounds are nitro substituted electron acceptor molecules, they can bind to π-donor sites by donor-acceptor interactions. Fluorescence property of most electron-rich fluorophores compounds can be effectively quenched by nitro-aromatic compounds through electron transfer. Many hydroxyl groups are on the surface of ZnO NPs. Hence, when electron-deficient PA is added to ZnO NP solution, it may possibly be bound to the electron rich hydroxyl group present on the surface of ZnO NPs which causes quenching of fluorescence property of the solution where the excited electron is trapped by electron transfer mechanism5,27,29. The fluorescence quenching image of picric acid adsorbed on a TLC plate was shown in Figure 3b. A linear calibration curve of quenching efficiency with concentration of PA (up to 100 µM) is observed with correlation of coefficient (R=0.97) (Inset of Figure 8). The fluorescence quenching efficiency of ZnO NPs was studied using Stern-Volmer plot presented in Figure 8 equation (I0/I vs [Q] where, I0 represents fluorescence intensity in the absence of quencher (PA), I denotes fluorescence intensity in presence of various concentration of picric acid and Q is the concentration of quencher. By using the plot in Figure 8, the detection limit was found to be 1.83 µM for ZnO NPs using the equation 3σ/slope. Further, to study the electron transfer process in the quenching mechanism of picric acid, the highest occupied molecular orbital (HOMO) level and lowest unoccupied molecular orbital (LUMO) level of ZnO NPs was obtained using cyclic voltammetry studies Figure 9. Figure S5 shows the energy levels for ZnO NPs and PA. The onset oxidation peak potential of ZnO NPs was observed at 0.76 V subsequently the onset reduction peak potential was observed at -0.46 V. The HOMO energy level was calculated from onset oxidation potential using the following equation HOMO = -eV (Eoxonset - E1/2 ferrocene + 4.8) and LUMO = -eV (Eredonset- E1/2 ferrocene + 4.8) respectively. The electron transfers from the ZnO NPs with 4.89 eV (HOMO) and 3.66 (LUMO) values may result in the quenching process. The energy gap (0.7 eV) between the HOMO of ZnO NPs (4.89 eV) and the LUMO of PA (4.19 eV) was lesser than the energy gap (1.2 eV) between the HOMO (4.89 eV) and LUMO (3.66 eV) of ZnO NPs. The HOMO and LUMO levels of ZnO NPs were compared with the reported PA HOMO and LUMO energy levels. The fluorescence quenching of ZnO NPs may be due to the energy transfer between PA and ZnO NPs27,30,31.
Figure 8. Stern-Volmer plot of ZnO NPs in aqueous solution with the addition of picric acid. Inset shows the relative fluorescence intensity with concentration up to 100 µM.
Figure 9. Cyclic voltammetry of ZnO NPs in water as solvent a scan rate at 100 mV s-1.
The reproducibility of the ZnO NPs is the ability to produce the same responses for 5 times and the response has been measured Figure 10. Relative standard deviation was found to be 1.76%. The relative quenching of fluorescence intensity of ZnO NPs in the presence of 100 µM PA is 163.29 ± 1.76%.
Figure 10. Reproducibility of ZnO NPs with 100 µM of PA.
The fluorescence nature of the ZnO NPs can be utilized for the bioimaging application. The NPs were treated with PBS33 to evaluate the fluorescence property of the particle and the prepared sample was placed on a microscope slide to acquire the fluorescence image. As shown in Figure 11, Unexpectedly the ZnO NPs exhibited blue fluorescence and green fluorescence. The photoluminescence measurements were conducted using long pass filters32. The obtained results indicate that ZnO NPs can also act as bioimaging probes or its application.
Figure 11. Fluorescence microscopy images of ZnO nanoparticle dispersed in PBS solution and the image was taken in a) green and b) blue filter.
In conclusion, we synthesized fluorescent ZnO NPs with enhanced fluorescence using Boswellia ovalifoliolata extract. The ZnO NPs exhibited high selectivity, sensitivity, low cost and efficient in sensing picric acid. The fluorescenct property of ZnO NPs in aqueous media makes it more potential and can be used as a fluorescent sensor for detection of picric acid and also in bioimaging application. Further, the biocompatibility of the nanoparticle needs to be studied for the cellular imaging and biotechnology application. Hence, the synthesized ZnO nanoparticle can be utilized effectively for sensing picric acid.
The authors are thankful to VIT University for the financial support and facilities provided to us. Authors acknowledge Dr. G. Sathiyan for the valuable suggestions and discussions for this paper. We thank Prof. K. Suthindhiran and his student R. Varalakshmi for the kind help with the fluorescence microscopy image. We thank Ms K. Shalinidevi for giving support for the cyclic voltammetry analysis.
The authors declare no competing financial interest.
